Pneumatech PPNG SolarNitro High-Pressure Nitrogen Skid
The Pneumatech PPNG SolarNitro Skid HE provides a complete, on-site solution for producing high-pressure nitrogen while taking advantage of available solar energy or lower-cost electricity periods. The system can be programmed to operate when energy is most abundant or affordable, helping facilities reduce energy costs while maintaining a reliable nitrogen supply.
Its all-in-one design combines a VSD compressor, air treatment, PSA nitrogen generator, high-pressure booster, storage, and intelligent controls on a single skid for simplified installation and operation.
- All-in-one, skid-mounted nitrogen generation system
- High-efficiency PSA nitrogen generator
- Nitrogen purity up to 99.999%
- 40-bar and 300-bar configurations
- VSD compressor with integrated refrigerant dryer
- 300-bar high-pressure booster
- Built-in nitrogen storage
- Four-stage filtration
- Purelogic™ controller
- Built-in PLC for energy scheduling
- Optional 24/7 ICONS remote monitoring
- Single power supply for the complete skid
Optimize Solar Energy Use
Schedule nitrogen production during periods of surplus solar power, allowing your facility to make better use of its available renewable energy.
Reduce Energy Costs
The system can operate during peak solar production or lower electricity tariff periods to help reduce nitrogen production costs.
Generate High-Purity Nitrogen On-Site
Produce nitrogen at purity levels up to 99.999% while reducing reliance on externally supplied nitrogen.
Simplify Installation
All major components are built, piped, and tested together on one skid with a single power connection.
Improve System Control
Integrated PLC and Purelogic controls manage nitrogen flow, purity, pressure, and energy scheduling from one system.
- Technology: Pressure Swing Adsorption (PSA)
- Nitrogen Purity: 99.95%–99.999%
- Outlet Pressures: 40 or 300 barg
- Ambient Temperature: 41–122°F
- Power Supply: 400V / 3-phase / 50 Hz
- 60 Hz Option: 460V / 3-phase / 60 Hz available upon request
- Lower Purity Levels: Available upon request
- Alternative Outlet Pressures: Available upon request
- Technology: Membrane nitrogen generation
- Nitrogen Purity: 90%–99.5%
- Inlet Pressure Range: 4–13 bar / 60–189 PSI
- Inlet Temperature Range: 41–122°F
- Required Inlet Air Quality: ISO 8573-1:2010 Class 1-4-1
- Power Requirement: No external power supply required for standard operation
