Quincy QGV Series | 75 hp - 200 hp

A variable speed air compressor utilizes a specialized drive that dynamically adjusts the compressor’s speed, ensuring more consistent pressure and helping to protect against power surges. This technology leads to significant energy savings, with many users noticing a substantial reduction in their energy costs over time.

The Quincy QGV® variable speed rotary screw air compressor offers top-tier pressure stability, with up to 85% turndown. Featuring a durable flex-drive airend with a 100,000-hour design, the QGV® delivers low operating costs, easy maintenance, and consistent reliability. Real-time monitoring is made simple with its full-color, touch-screen interface and graphical performance analysis.

 Quincy QGV 75-200hp Brochure

Quincy QGV Series | 75 hp - 200 hp​

• Direct drive airend, 460 or 575 volt, 75-150 psig
• Automatic restart
• Low demand mode
• Factory mounted and tested Variable Frequency Drive assembly
• Heavy-duty intake filter
• 104° – 110°F max ambient capability
• Integrated compressor networking
• Choice of long-life QuinSyn® fluids
• Two-stage air/fluid separation
• Low-sound enclosure
• Remote alarm communication
• Flexible coupling
• Speed Optimizer Control
• 10-year Royal Blue Warranty



  • 82 – 982 cfm, 75-150 psig
  • Sound levels as low as 68 dBA
  • Standard low sound enclosure
  • Full color touch-screen display
  • 10-Year Royal Blue Warranty
  • Direct-drive airend
  • Heavy duty intake filter
  • Holds pressure +/- 2 psi
  • Unique low demand mode
  • Low power consumption

• Line reactors
• Water-cooled on QGV 75 to 200
• Remote monitoring
• Remote Pressure Transducer
